Features

Built to deliver 80 Plus Bronze with 88% power efficiency, The smart BX1 series is available in 450W - 750W models. Constructed with a 120mm hydraulic bearing fan, Japanese main capacitor and other premium components to help deliver a continuous and stable power output at 40℃, Near silent operation and reliable performance. With an ample 5-year , The smart BX1 is able to satisfy the market, where value-oriented users are looking for a new power Supply with all the latest features. P/N: PS-SPD-0550NNFABU-1 WATTS: 550W RGB FAN: No FORM FACTOR: ATX MODEL: SPD-550AH2NKB TYPE: ATX 12V v2.3 and EPS v2.92 MAX. OUTPUT CAPACITY: 550W PEAK OUTPUT CAPACITY: 660W COLOR: Black DIMENSION ( W / H / D ): 150mm(W) x 86mm(H) x 140mm(D) PFC (POWER FACTOR CORRECTION): Active PFC POWER GOOD SIGNAL: 100-500 msec HOLD UP TIME: 16msec at 70% of full load INPUT CURRENT: 10A max INPUT FREQUENCY RANGE: 50Hz - 60Hz INPUT VOLTAGE: 100V – 240V~ OPERATING TEMPERATURE: 5°C toplus 40°C OPERATING HUMIDITY: 20% to 85%,non-condensing STORAGE TEMPERATURE: -40°C toplus 55°C STORAGE HUMIDITY: 10% to 95%, non-condensing COOLING SYSTEM: 12cm hydraulic bearing fan EFFICIENCY: Meet 80 PLUS Gold at 115Vac input. MTBF: 100,000 hrs minimum SAFETY APPROVAL: CE/CB/TUV/UL/FCC/BSMI PCI-E 6+2PIN: 2.

80+ BRONZE - Efficiency up to 88% and optimized for C6/C7 States Ready
CONNECTORS - 24 Pin x 1 / 4+4 Pin x 1 / SATA x 6 / PCI-E x 2 / Peripheral x 4 / FDD x 1
ULTRA QUIET 120MM FAN - Dynamic bearing fan guarantees superior cooling performance and silent operation
MAIN JAPANESE CAPACITORS - Japanese capacitors provide superb performance and reliability
LOW RIPPLE NOISE - Ensure excellent power supply stability; keep performance-critical components, such as VGA card, to operate reliably for longer

Shipping Note: Shipping to Alaska, Hawaii, PO Boxes, and APO addresses is not available for this item

Warranty: 90 Day Woot Limited Warranty

Specs

In the Box:

(1) Thermaltake Smart BX1 550W Bronze SLI/ CrossFire Ready Continuous Power ATX12V V2.3/ EPS V2.92 80 Plus Bronze Certified Non Modular Power Supply PS-SPD-0550NNFABU-1

PRIME MEMBERS

Thermaltake Smart BX1 550W Bronze SLI/ CrossFire Ready Continuous Power ATX12V V2.3/ EPS V2.92 80 Plus Bronze Certified Non Modular Power Supply PS-SPD-0550NNFABU-1
